{"id":7541261467759,"title":"Prismatic Battery, 100Ah, 3.2V, Grade A Lithium-ion LiFePO4 Prismatic Cell","handle":"prismatic-battery-100ah-3-2v-grade-a-lithium-ion-lifepo4-prismatic-cell-copy","description":"\u003cp\u003e1. Rated Capacity\u003cbr\u003e - Typical Capacity: 30Ah (achieved with 0.5C discharge after standard charge)\u003cbr\u003e - Minimum Capacity: 29.5Ah\u003c\/p\u003e\n\u003cp\u003e2. Nominal Voltage\u003cbr\u003e - Voltage: 3.2V (mean operating voltage)\u003c\/p\u003e\n\u003cp\u003e3. Voltage at End of Discharge\u003cbr\u003e - Cut-off Voltage: 2.0V\u003c\/p\u003e\n\u003cp\u003e4. Charging Voltage\u003cbr\u003e - Voltage: 3.65V\u003c\/p\u003e\n\u003cp\u003e5. Internal Impedance\u003cbr\u003e - Resistance: ≤2mΩ (measured at AC 1kHz after 50% charge)\u003cbr\u003e - Measurement Conditions: New batteries within one week of shipment and fewer than 5 cycles\u003c\/p\u003e\n\u003cp\u003e6. Standard Charge\u003cbr\u003e - Method: Constant current of 0.5C5A until 3.65V, then constant voltage until current drops to 0.05C5A\u003cbr\u003e - Charge Time: Approximately 3.0 hours\u003c\/p\u003e\n\u003cp\u003e7. Standard Discharge\u003cbr\u003e - Method: Constant current of 0.5C5A until voltage drops to 2.0V\u003c\/p\u003e\n\u003cp\u003e8. Fast Charge\u003cbr\u003e - Method: Constant current of 1C5A until 3.65V, then constant voltage until current drops to 0.05C5A\u003cbr\u003e - Charge Time: Approximately 1.5 hours\u003c\/p\u003e\n\u003cp\u003e9. Fast Discharge\u003cbr\u003e - Method: Constant current of 1C5A until voltage drops to 2.0V\u003c\/p\u003e\n\u003cp\u003e10. Maximum Continuous Charge Current\u003cbr\u003e - Current: 1.0C5A\u003c\/p\u003e\n\u003cp\u003e11. Maximum Continuous Discharge Current\u003cbr\u003e - Current: 2.0C5A (up to 3.0C5A for less than 10 seconds, with SOC ≥20%)\u003c\/p\u003e\n\u003cp\u003e12. Operation Temperature Range\u003cbr\u003e - Charging: 0 to 45°C\u003cbr\u003e - Discharging: -20 to 55°C\u003cbr\u003e - Humidity: 60±25% RH (bare cell)\u003c\/p\u003e\n\u003cp\u003e13. Storage Temperature Range\u003cbr\u003e - Less than 1 year: -10 to 30°C\u003cbr\u003e - Less than 3 months: -10 to 40°C\u003cbr\u003e - Humidity: 60±25% RH (at shipment state)\u003c\/p\u003e\n\u003cp\u003e14. Battery Dimensions\u003cbr\u003e - Height: 132.2mm±0.8mm\u003cbr\u003e - Length: 173.9mm±0.5mm\u003cbr\u003e - Width: 48.0mm±0.5mm\u003c\/p\u003e\n\u003cp\u003e15. Battery Weight\u003cbr\u003e - Weight: 2.3Kg\u003c\/p\u003e\n\u003cp\u003eThis specification ensures the VP-LFP100 cell delivers reliable performance under specified conditions and is suitable for a wide range of applications.\u003c\/p\u003e\n\u003c!----\u003e\u003c!----\u003e","published_at":"2024-06-26T12:08:34-04:00","created_at":"2024-06-19T04:32:46-04:00","vendor":"Voltaplex Energy","type":"","tags":[],"price":0,"price_min":0,"price_max":0,"available":false,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42197398683759,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":null,"requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Prismatic Battery, 100Ah, 3.2V, Grade A Lithium-ion LiFePO4 Prismatic Cell","public_title":null,"options":["Default Title"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_iso_e2d359a3-c4c4-4195-ae27-5824c25d5d1a.jpg?v=1718785702","\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_angle_bb2751ea-626b-4986-83d3-0d59981757cc.jpg?v=1718785702","\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_eaed46c6-4bfb-4d64-804b-1a3fa1253017.jpg?v=1718785702"],"featured_image":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_iso_e2d359a3-c4c4-4195-ae27-5824c25d5d1a.jpg?v=1718785702","options":["Title"],"media":[{"alt":null,"id":26659880927343,"position":1,"preview_image":{"aspect_ratio":1.0,"height":310,"width":310,"src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_iso_e2d359a3-c4c4-4195-ae27-5824c25d5d1a.jpg?v=1718785702"},"aspect_ratio":1.0,"height":310,"media_type":"image","src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_iso_e2d359a3-c4c4-4195-ae27-5824c25d5d1a.jpg?v=1718785702","width":310},{"alt":null,"id":26659880861807,"position":2,"preview_image":{"aspect_ratio":1.0,"height":310,"width":310,"src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_angle_bb2751ea-626b-4986-83d3-0d59981757cc.jpg?v=1718785702"},"aspect_ratio":1.0,"height":310,"media_type":"image","src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_angle_bb2751ea-626b-4986-83d3-0d59981757cc.jpg?v=1718785702","width":310},{"alt":null,"id":26659880894575,"position":3,"preview_image":{"aspect_ratio":1.0,"height":310,"width":310,"src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_eaed46c6-4bfb-4d64-804b-1a3fa1253017.jpg?v=1718785702"},"aspect_ratio":1.0,"height":310,"media_type":"image","src":"\/\/voltaplex.com\/cdn\/shop\/files\/lithium_ion_prismatic_battery_al_72ah_top_eaed46c6-4bfb-4d64-804b-1a3fa1253017.jpg?v=1718785702","width":310}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003e1. Rated Capacity\u003cbr\u003e - Typical Capacity: 30Ah (achieved with 0.5C discharge after standard charge)\u003cbr\u003e - Minimum Capacity: 29.5Ah\u003c\/p\u003e\n\u003cp\u003e2. Nominal Voltage\u003cbr\u003e - Voltage: 3.2V (mean operating voltage)\u003c\/p\u003e\n\u003cp\u003e3. Voltage at End of Discharge\u003cbr\u003e - Cut-off Voltage: 2.0V\u003c\/p\u003e\n\u003cp\u003e4. Charging Voltage\u003cbr\u003e - Voltage: 3.65V\u003c\/p\u003e\n\u003cp\u003e5. Internal Impedance\u003cbr\u003e - Resistance: ≤2mΩ (measured at AC 1kHz after 50% charge)\u003cbr\u003e - Measurement Conditions: New batteries within one week of shipment and fewer than 5 cycles\u003c\/p\u003e\n\u003cp\u003e6. Standard Charge\u003cbr\u003e - Method: Constant current of 0.5C5A until 3.65V, then constant voltage until current drops to 0.05C5A\u003cbr\u003e - Charge Time: Approximately 3.0 hours\u003c\/p\u003e\n\u003cp\u003e7. Standard Discharge\u003cbr\u003e - Method: Constant current of 0.5C5A until voltage drops to 2.0V\u003c\/p\u003e\n\u003cp\u003e8. Fast Charge\u003cbr\u003e - Method: Constant current of 1C5A until 3.65V, then constant voltage until current drops to 0.05C5A\u003cbr\u003e - Charge Time: Approximately 1.5 hours\u003c\/p\u003e\n\u003cp\u003e9. Fast Discharge\u003cbr\u003e - Method: Constant current of 1C5A until voltage drops to 2.0V\u003c\/p\u003e\n\u003cp\u003e10. Maximum Continuous Charge Current\u003cbr\u003e - Current: 1.0C5A\u003c\/p\u003e\n\u003cp\u003e11. Maximum Continuous Discharge Current\u003cbr\u003e - Current: 2.0C5A (up to 3.0C5A for less than 10 seconds, with SOC ≥20%)\u003c\/p\u003e\n\u003cp\u003e12. Operation Temperature Range\u003cbr\u003e - Charging: 0 to 45°C\u003cbr\u003e - Discharging: -20 to 55°C\u003cbr\u003e - Humidity: 60±25% RH (bare cell)\u003c\/p\u003e\n\u003cp\u003e13. Storage Temperature Range\u003cbr\u003e - Less than 1 year: -10 to 30°C\u003cbr\u003e - Less than 3 months: -10 to 40°C\u003cbr\u003e - Humidity: 60±25% RH (at shipment state)\u003c\/p\u003e\n\u003cp\u003e14. Battery Dimensions\u003cbr\u003e - Height: 132.2mm±0.8mm\u003cbr\u003e - Length: 173.9mm±0.5mm\u003cbr\u003e - Width: 48.0mm±0.5mm\u003c\/p\u003e\n\u003cp\u003e15. Battery Weight\u003cbr\u003e - Weight: 2.3Kg\u003c\/p\u003e\n\u003cp\u003eThis specification ensures the VP-LFP100 cell delivers reliable performance under specified conditions and is suitable for a wide range of applications.\u003c\/p\u003e\n\u003c!----\u003e\u003c!----\u003e"}
